Twist the red and red/white wires together and twist the black and
black/white wires together before connecting to vehicle power.
Connect the green wire to vehicle ground:
Power Cable Installation
1. The Thor VM1 must not be mounted in the Quick Mount
Smart Dock. The power switch on the dock must be turned
Off. The power cable must be UNPLUGGED from the
dock.
2. While observing the Fuse Requirements in panel 2, con-
nect the power cable as close as possible to the actual bat-
tery terminals of the vehicle (if using unswitched power).
For battery powered vehicles:
The green wire must be connected to the vehicle chassis
ground.
For internal combustion engine powered vehicles:
The green wire is connected to the vehicle chassis ground,
which can also be battery negative.
Wire Color Connection
Red DC + (10-60 VDC)
Red/White DC + (10-60 VDC)
Black DC -
Black/White DC -
Green Ground
Blue Ignition Input (optional)
Refer to the Thor VM1 User’s Guide,
available at www.honeywellaidc.com, for
further information about ignition control.
