Honeywell TOUCHDOWN - CANOPY INSTALLATION; Final Canopy Securing

12
CANOPY INSTALLATION
Mounting
Bracket
Canopy
Fig. 18
18. Lift the canopy up so the partially installed
mounting bracket screws are situated in the L-slots
on each side of the canopy. Rotate the canopy
clockwise and install the two remaining mounting
bracket screws and washers from Step 4 (Fig.18).
Mounting Bracket
Screw
Washer
Mounting
Bracket Screw
and Washer
