Fig. 5
6
MOUNTING BRACKET INSTALLATION
Fig. 4
Mounting
Bracket
Screws
Mounting
Bracket
Canopy
Washer
5. Secure the mounting bracket to the outlet box using
screws and washers provided with the outlet box
(not included) (Fig. 5).
Note: It is very important that you use proper hardware
when installing the mounting bracket as it supports
the fan.
Important: If using the angle mount, ensure that the
open end of the mounting bracket is installed facing
the peak of the ceiling.
4. Loosen the four mounting bracket screws.
Completely remove the two mounting bracket
screws and washers from the round holes in the
canopy. Set aside for later use. Detach mounting
bracket from the canopy (Fig. 4).
Mounting Bracket
Screw
Washer
