15
LIGHT KIT INSTALLATION
27. Snap the end of the pull chain extensions or
custom pull chain extensions (sold separately) onto
the ends of the appropriate pull chains (Fig. 27).
Fig. 26
Fig. 27
Glass Shade
Socket Ring
Socket Ring Tool
Light
Pull Chain
Fan
Pull Chain
Socket
Bulb
26. Install each bulb (Fig. 26).
Important: When you need to replace the bulb,
please allow bulb and light kit to cool down before
touching the bulb or the light kit.
Fig. 25
25. Remove socket ring from socket. Lift glass shade
onto the light kit and secure with socket ring using the
socket ring tool. Repeat for each socket (Fig. 25).
Light Pull Chain Fan Pull Chain
