Servicing the Thermostat
Heat Anticipator Setting
The T8090T Thermostat has an adjustable
heat anticipator that was factory-set at 0.1A.
The heat anticipator must be set at 0.1A for
proper system operation. See Fig. 6.
M8596
MOVE
INDICATOR
TO 0.1A
Fig. 6—Heat anticipator setting.
