Follow the appliance manufacturer’s instructions.
The information below will assist in typical control
applications, but the specific controls may require
special manufacturer instructions.
LIGHTING THE MAIN BURNER
STOP: Read the warning above.
This appliance has a pilot burner which must be lit by
hand. If the pilot flame has gone out, follow these instruc-
tions exactly.
1. Set the thermostat to lowest setting.
2. Turn off all electric power to the appliance.
3. Remove control access panel.
4. Push in gas control knob (refer to Fig. 3 or 4) slightly
and turn clockwise
m
to OFF.
NOTE: Knob cannot be turned from PILOT to OFF unless
knob is pushed in slightly. Do not force.
5. Wait five (5) minutes to clear out any gas. If you then
smell
gas,
STOP! Follow item 1 in the Warning (page 14).
If you don’t smell gas, go to next step.
6. Remove the pilot access panel located below and
behind the gas control unit.
7. Find the pilot—follow metal tube from gas control.
The pilot is between the two burner tubes behind the pilot
access panel.
8. Turn knob on gas control counterclockwise
m
t o
PILOT.
9. Push in control knob all the way and hold in.
immedi-
ately
Iightthe pilot with a match. continue to hold the control
knob in for about one (1) minute afterthepilot
islit.
Release
knob and it will pop back up. Pilot should remain lit. If it goes
out, repeat steps 5-10.
10. Replace pilot access panel.
11. Turn gas control knob counterclockwise
n
to
ON.
12. Replace control access panel.
13. Turn on all electric power to the appliance.
14. Set thermostat to desired setting.
To Turn Off Appliance
VACATION SHUTDOWN—Set thermostat to desired
control temperature while you are away.
COMPLETE SHUTDOWN—Push in gas control knob
slightly and turn clockwise
m
to OFF. Do not force.
Appliance will completely shut off. Follow lighting proce-
dure above to resume normal operation,
15
60-2019—7
