VR8105, VR8205, AND VR8305 DIRECT IGNITION COMBINATION GAS CONTROLS
69-1226—04 2
SPECIFICATIONS
Body Pattern: Straight through; See Table 1 for inlet and
outlet size.
Electrical Ratings:
Voltage and Frequency: 24 Vac, 60 Hz or 50/60 Hz
depending on model.
Current Draw: 0.5A with both operators energized.
Capacity: See Table 1.
Conversion:
Use conversion factors in Table 2 to convert capacities for
other gases.
Regulation Range: See Table 1.
Natural-LP Gas Conversion Kits: See Table 4.
Pipe Adapters:
Angle and straight adapters available for 3/8-, 1/2- and
3/4-in. pipe. See Table 5. Flange kits include one
flange with attached O-ring, four mounting screws, a
9/64 in. hex wrench and instructions.
Approvals:
American Gas Association Design Certificate: L2025006.
Canadian Gas Association Design Certificate: L2025006.
Australian Gas Association Design Certificate: 4214.
Approved for Delta C applications.
European Community (CE) Certificate: Pending.
PLANNING THE INSTALLATION
Fire or Explosion Hazard.
Can cause severe injury, death or property
damage.
Follow these warnings exactly:
1. Plan the installation as outlined below.
2. Plan for frequent maintenance as described in
the Maintenance section.
Heavy demands are made on the controls when direct
ignition systems are used on central heating equipment in
barns, greenhouses, and commercial properties and on
heating appliances such as commercial cookers,
agricultural equipment, industrial heating equipment and
pool heaters.
Special steps may be required to prevent nuisance
shutdowns and control failures due to frequent cycling,
severe environmental conditions related to moisture,
corrosive chemicals, dust or excessive heat. These
applications require Honeywell Engineering review;
contact your Honeywell Sales Representative for
assistance.
Review the following conditions that can apply to your
specific installation and follow the precautions suggested.
Frequent Cycling
this control is designed for use on appliances that typically
cycle three to four times an hour only during the heating
season. In year-around applications with greater cycling
rates, the control can wear out more quickly. Perform a
monthly check.
Table 4. Natural-LP Gas Conversion Kits.
Table 5. Flange Adapter Part Numbers.
a
Flange kits include one flange, one O-ring and four mounting screws.
b
Do not use flanges on control models with 3/4 in. inlet and 3/4 in. outlet. On models with 1/2 in. inlet and 3/4 in. outlet,
use flanges only on the 1/2 in. inlet side.
Table 6 shows additional specifications for the CE-only
models.
Model No. Suffix Letter Kit to Convert Natural Gas to LP Kit to Convert LP to Natural Gas
H, K, M 393691 394588
P Not field convertible. Not field convertible.
Q 396021 396025
R Not required, convertible valve. Not required, convertible valve.
Inlet/Outlet Pipe
Size (in. NPT) Flange Type
Part Number
a,b
Without Hex Wrench With Hex Wrench
3/8 Straight 393690-1 393690-11
3/8 Elbow 393690-2 393690-12
1/2 Straight 393690-6 393690-16
1/2 Elbow 393690-3 393690-13
3/4 Straight 393690-4 393690-14
3/4 Elbow 393690-5 393690-15
To Next Page
