Honeywell Viewguard DUAL AM FAI User Manual

3
Installation Instructions Viewguard DUAL / AM FAI
7. Technical specification
Operating voltage Vnom 12 V DC
Operating voltge range 8.0 V to 15 V DC
Current consumption at Vnom=12 V DC 6.6 mA
Range (programmable): 8 / 11 / 13 / 15 m
PIR and MW together
PIR sensor temperature-compensated
PIR sensitivity (programmable): normal / high
(only 033440/450) up to 30 cm
Frequency microwave:
- 033440 / 033441 9.35 GHz (X band)
- 033450 / 033451 10.587 GHz (X band)
Installation position vertical, optics at bottom
Alarm contact:
- Contact rating 15 V DC / 0.1 A
- Internal resistance 25
- Contact position open in the event of alarm
Fault contact:
- Contact rating 15 V DC / 0.1 A
- Internal resistance 25
- Contact position open in the event of fault
Tamper contact:
- Contact rating 15 V DC / 0.1 A
- Internal resistance 10
- Contact position open in the event of tamper
Protection category as per EN 60529 IP 30
Environmental class as per VdS II
Operating temperature range -10 °C to +55 °C
Storage temperature range -25 °C to +70 °C
DimensionsWxHxD 64x158x48mm
Colour White
(similar to RAL 9010)
Anti-Mask function
£W
£W
£W
8. Accessories
033390 Adjustable joint
033588 Ball-and-socket set for wall and corner mounting
033391 Seal
Swivel range: Horizontal
Vertical +4° up to -8°
(PU = 20 piece)
±20°
033440 / 033450 Viewguard DUALAM FAI DIN CLC/TS 50131-2-4 grade 3
033441 / 033451 Viewguard DUAL FAI DIN CLC/TS 50131-2-4 grade 2
The detectors Viewguard DUAL AM FAI, Item no. 033440 / 033450 and Viewguard DUAL
FAI, Item no. 033441 / 033451 when used as intended, comply with the basic require-
ments of Article 3 of the R&TTE
TheEU conformitydeclaration canbe downloadedat
"www.honeywell.com/security/de" under Service-/ Download.
Thedevices mayonly besold andoperated inthe followingcountries:
Germany, Austria, Switzerland, Liechtenstein, Poland, Slovakia, Czech Republic,
Luxembourg,Turkey, Greece, Latvia, Lithuania, Hungary, Belgium and Netherlands.
France,Spain, Italy, Portugaland UnitedKingdom.
9. EU conformity
033440 / 033441:
033450 / 033451:
6. LED indication
on
flashing
blanked
1)
No LED indication in Easy Logic mode
2)
See table in Chapter 4.1 "Function of inputs", function c).
Operating Mode Red Yellow What Indication reset
Start up When power on After 30 sec.
Walk test Motion detected
Covering detected
Failed self test
After disarming First alarm Clear signal from control panel
with preceding
alarm Subsequent alarm
Normal operation
Automatically without motion
When covering is removed
When fault is eliminated
Clear signal from control panel
1)
2)
2)
Subject to change without notice
LED yellow: see Fig. 2-
LED red: see Fig. 2-


