Honeywell VisionPRO Series Installation Guide

2
Current display. Underlined label
signifies the current display.
Mode control buttons. Use to change
settings for Fan or System Heat/Cool.
Menu. Select options to: set schedules,
view equipment status, change IAQ
settings, access installer options*, etc.
Current status. Shows system mode
(heat/cool), outdoor temperature and
humidity (with optional outdoor sensor).
Current schedule. Shows desired
temperature and schedule status.
Indoor conditions. Shows indoor
temperature and humidity.
Current Time.
Alert Light. On when alert
message is active or system is set to Em
Heat. Flashes for battery-only power; on
continuous for 24 VAC.
microSD Card Port. Use
card to load settings and dealer
information.
Reference to key features
* Password is the date code.
Getting started
Follow these basic steps to install this
thermostat, link it with the wireless
accessories, and set installer options.
1
Installing the thermostat
2
Powering optional RedLINK accessories
3
Performing initial setup
4
Finding your password (Date Code)
• To add or remove RedLINK accessories
• To make changes to Installer Setup
• To perform an Installer Test
M34164A
XXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXX XXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXX
RoHs Compliant
Conformité RoHs
Assembled in Mexico
Assemblé au Mexique
TH8321R1001
1
1324
M34161A
XXXXXXXXXXXXXXXXX XXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXX XXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXX
RoHs Compliant
Conformité RoHs
Assembled in Mexico
Assemblé au Mexique
TH8321R1001
1
1324
Thermostat (back view)
Password
(Date Code)
