Functions of the Keypads
(cont’d)
NOTE:
The functions printed directly on
the keys indicate their primary purpose; the
functions printed under some of the keys
(shown in brackets under the respective
key), indicate their alternate or secondary
purpose.
1. DISPLAY WINDOW
Alpha Display Keypads:
2-line, 32-
character Liquid Crystal Display (LCD)
keypads that display protection point
identification, system status, and
messages.
Fixed-Word Display Keypads:
Display protection zone ID and system
status messages using pre-designated
words in the LCD display area.
2.
1
OFF
Disarms burglary portion of
the
system, silences alarms and
audible trouble indicators, and clears
visual display after problem's
correction.
[RECORD]
On Voice keypads, used in
conjunction with the FUNCTION and
VOICE keys to record up to a 2.5-
minute message.
3.
2
AWAY
Arms the entire burglary
system,
perimeter and interior.
[VOLUME]
On Voice keypads, used in
conjunction with the FUNCTION and
desired volume control keys
↑
[3] or
↓
[6] to adjust the volume of a recorded
message or voice system status.
4.
3
STAY
Arms perimeter portion of
burglary system only. Interior
protection is not armed, allowing
movement within premises without
causing an alarm.
[
PLAY
]
On Voice keypads, used in
conjunction with the FUNCTION and
VOICE keys to play the recorded
message.
[
↑
]
On Voice keypads, used in
conjunction with the FUNCTION and
VOLUME keys to raise the message
and voice system status volume.
5.
4
MAX
Arms the entire burglary
system, perimeter and interior, but
without entry delay feature. Entering
via an entry/exit door will cause an
alarm.
6.
5
TEST
Tests the system and alarm
sounder if disarmed. Refer to
Testing
The System
section for test procedures.
7.
6
BYPASS
Removes individual
protection zones from being monitored
by the system.
[
↓
]
On Voice keypads, used in
conjunction with the FUNCTION and
VOLUME keys to lower the message
and voice system status volume.
8.
7
INSTANT
Arms in manner similar to
the STAY mode, but without the entry
delay feature.
Entering via an entry/exit door will
cause an alarm.
9.
8
CODE
Used to assign additional user
codes for other users of the system.
10.
9
CHIME
Turns CHIME mode on and
off.
When on, the opening of windows or
doors while the system is disarmed will
sound 3 beeps at the keypad(s).
