Honeywell VISTA-20PSeries - Functions of the Keypads

– 11 –
Functions of the Keypads
1
OFF
4
MAX
7
INSTANT
READY
2
AWAY
5
TEST
8
CODE
0
3
STAY
6
BYPASS
9
CHIME
#
ARMED
READY
6160V-00-007-V0
MESSAGE
MIC
RECORD
VOLUME
PLAY
STATUS
VOICE
FUNCTION
12
11
10
8
7
9
13
2
34
6
5
1
18
17
16
15
14
20
19
Voice-capable 2-line Alpha keypad
(shown with flip-down front door removed)
IMPORTANT!
•
Match the numerical callouts in the above graphic with the corresponding number on the
following pages for a description of usage.
•
When entering codes and commands, sequential key depressions must be made within 4-5
seconds of one another. If 4-5 seconds elapse without a key depression, the entry will be
aborted and must be repeated from its beginning. Be sure to observe this precaution when
performing any of the procedures in this manual.
•
If you make a mistake while entering a
security
code, stop, press the [
✱
] key, and then
start over. If you stop in the middle while entering a code, and then immediately start
the entry over, an erroneous code might be entered.
