WEB-600E AND CP-600E NETWORK CONTROLLERS
19 62-0433—01
TAB MOUNTING DIMENSIONS
Measurements are in inches and (mm). Note that DIN mounting is recommended over tab mounting. See Fig. 1.
Fig. 10. Tab mounting dimentions.
1-64
DIA.
(4)
3-1/4
(83)
WEB-600E
IO-16-H
IO-16-H OR
NPB-PWR-H
NOTE:
DOCUMENT MAY NOT SHOW DIMENSIONS TO SCALE.
VERIFY ALL MEASUREMENTS BEFORE DRILLING.
ELECTRONIC AND PRINTED VERSIONS OF THIS
DIN MOUNTING IS RECOMMENDED OVER TAB MOUNTING.
SEE FIG. 1.
WEB-600E
NPB-PWR-H,
NPB-PWR-UN-H,
OR IO-16-H
NOTE: DISTANCE BETWEEN CENTER OF TABS FROM ONE
UNIT TO ANOTHER UNIT.
TIP: IF MOUNTING ACCESSORY MODULES, FUTURE
REMOVAL/REPLACEMENT OF THE CONTROLLER IS
SIMPLIFIED IF YOU DO NOT INSTALL SCREWS IN
THE “ACCESSORY MODULE SIDE” TABS OF THE
CONTROLLER (SEE ABOVE).
ACCESSORY
MODULE
SIDE TABS
M33924
2-1/2
(64)
6-23/32 (171)
4
(102)
3-3/4 (95)
2-1/2
(64)
6-23/32 (171)
3-1/4
(83)
3-31/64
(89)
