SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
31-00475-01 50
215.6 102 1393 0.53 284 140 1536 0.581
217.4 103 1396 0.531 285.8 141 1539 0.582
219.2 104 1400 0.532 287.6 142 1543 0.584
221 105 1404 0.534 289.4 143 1547 0.585
222.8 106 1408 0.535 291.2 144 1551 0.586
224.6 107 1412 0.537 293 145 1554 0.587
226.4 108 1415 0.538 294.8 146 1558 0.589
228.2 109 1419 0.539 296.6 147 1562 0.59
230 110 1423 0.541 298.4 148 1566 0.592
231.8 111 1427 0.542 300.2 149 1569 0.593
233.6 112 1430 0.543 302 150 1573 0.594
235.4 113 1434 0.545 303.8 151 1577 0.596
237.2 114 1438 0.546 305.6 152 1581 0.597
239 115 1442 0.547 307.4 153 1584 0.598
240.8 116 1446 0.549 309.2 154 1588 0.6
242.6 117 1449 0.55 311 155 1592 0.601
244.4 118 1453 0.551 312.8 156 1596 0.602
246.2 119 1457 0.553 314.6 157 1599 0.603
248 120 1461 0.554 316.4 158 1603 0.605
249.8 121 1464 0.555 318.2 159 1607 0.606
251.6 122 1468 0.557 320 160 1610 0.607
253.4 123 1472 0.558 321.8 161 1614 0.609
255.2 124 1476 0.56 323.6 162 1618 0.61
257 125 1479 0.561 325.4 163 1622 0.612
258.8 126 1483 0.562 327.2 164 1625 0.613
260.6 127 1487 0.564 329 165 1629 0.614
262.4 128 1491 0.565 330.8 166 1633 0.615
264.2 129 1494 0.566 332.6 167 1636 0.617
266 130 1498 0.567 334.4 168 1640 0.618
267.8 131 1502 0.569 336.2 169 1644 0.619
269.6 132 1506 0.57 338 170 1648 0.621
271.4 133 1510 0.572 339.8 171 1651 0.622
273.2 134 1513 0.573 341.6 172 1655 0.623
275 135 1517 0.574 343.4 173 1659 0.625
276.8 136 1521 0.576 345.2 174 1662 0.626
278.6 137 1525 0.577 347 175 1666 0.627
280.4 138 1528 0.578 348.8 176 1670 0.629
282.2 139 1532 0.58 350.6 177 1674 0.63
Table 39 PT1000 Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
To Next Page
