SPYDER MODEL 7 VAV CONTROLLER INSTALLATION INSTRUCTIONS
51 31-00475-01
352.4 178 1677 0.631 420.8 216 1817 0.68
354.2 179 1681 0.632 422.6 217 1821 0.681
356 180 1685 0.634 424.4 218 1824 0.683
357.8 181 1688 0.635 426.2 219 1828 0.684
359.6 182 1692 0.636 428 220 1832 0.685
361.4 183 1696 0.638 429.8 221 1835 0.686
363.2 184 1699 0.639 431.6 222 1839 0.688
365 185 1703 0.64 433.4 223 1843 0.689
366.8 186 1707 0.642 435.2 224 1846 0.69
368.6 187 1711 0.643 437 225 1850 0.692
370.4 188 1714 0.644 438.8 226 1854 0.693
372.2 189 1718 0.645 440.6 227 1857 0.694
374 190 1722 0.647 442.4 228 1861 0.695
375.8 191 1725 0.648 444.2 229 1865 0.697
377.6 192 1729 0.649 446 230 1868 0.698
379.4 193 1733 0.651 447.8 231 1872 0.699
381.2 194 1736 0.652 449.6 232 1875 0.7
383 195 1740 0.653 451.4 233 1879 0.702
384.8 196 1744 0.655 453.2 234 1883 0.703
386.6 197 1747 0.656 455 235 1886 0.704
388.4 198 1751 0.657 456.8 236 1890 0.705
390.2 199 1755 0.658 458.6 237 1894 0.707
392 200 1758 0.659 460.4 238 1897 0.708
393.8 201 1762 0.661 462.2 239 1901 0.709
395.6 202 1766 0.662 464 240 1905 0.711
397.4 203 1769 0.663 465.8 241 1908 0.712
399.2 204 1773 0.665 467.6 242 1912 0.713
401 205 1777 0.666 469.4 243 1915 0.714
402.8 206 1780 0.667 471.2 244 1919 0.716
404.6 207 1784 0.669 473 245 1923 0.717
406.4 208 1788 0.67 474.8 246 1926 0.718
408.2 209 1791 0.671 476.6 247 1930 0.719
410 210 1795 0.672 478.4 248 1934 0.721
411.8 211 1799 0.674 480.2 249 1937 0.722
413.6 212 1802 0.675 482 250 1941 0.723
415.4 213 1806 0.676 483.8 251 1944 0.724
417.2 214 1810 0.678 485.6 252 1948 0.726
419 215 1813 0.679 487.4 253 1952 0.727
Table 39 PT1000 Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
To Next Page
