Honeywell XNX-BT Series Technical Manual

XNX Universal Transmitter
Introduction
28
Conguration Mode
Select Language
Set Date & Time
Set Date Format
Set Year, Month, Day
Set Hours, Minutes, Seconds
Sensor Type Selection
Set mV Sensor Type
9
Set mA Sensor Type
10
Gas Selection
Changing the Gas or Units Name
Gas Selections and Alarm Limits Based on mV
Sensor Type
Range & Alarms
Set Range
Alarm 1 Type
Alarm 1 Setpoint
Alarm 1 Latching or Non-latching
Alarm 2 Type
Alarm 2 Setpoint
Alarm 2 Latching or Non-latching
Selecting the Numeric Format
Latching/Non-latching
Change Meas. Units
11
mA Output Levels
Change mA for Inhibit
9 Catalytic bead sensor only
10 Searchpoint Optima and Searchline Excel only
11 ECC and mV only
Change mA for Warning
Change mA for Overrange
Change mA for Low Signal
Change mA for Blocked Beam
Set Calibration Interval
Accept New Sensor Type
12
Information screen identifying previous sensor and
new sensor
Screen displays new type and old type
Set Beam Block
13
Select Beam Block Threshold
Select Time to Beam Block
Select Time to Fault
Set Path Length
14
Set New Path Length
Congure Unit ID
Edit ID
Clear ID
Default ID
Relay Options
15
Select A1
Select A2
Fieldbus Options
16
Change Fieldbus Address
Change Fieldbus Speed
Security
Reset and LVL1
LVL1 Code
LVL2 Code
12 Electrochemical and catalytic bead sensors only
13 Searchline Excel only
14 Searchline Excel only
15 Optional relay only
16 Optional FOUNDATION Fieldbus and Modbus only
