Honeywell XNX-UT Series Technical Manual

XNX Universal Transmitter
HART Protocol
190
E. Calibration
1. Gas calibrn
2. Bump test
3. Calibrate mA offset
4. Soft reset
5. Align Excel
F. Configuration
1. Config security
2. Measure as mg/m3
3. Set range & alarm
4. Config alarm mode
5. Fieldbus option
6. Set mV sensor type
7. Gas selection
8. Config mA status l…
9. Set Calibrn interval
XNX ID (e.g., South tower)
Conc unit (%LEL)
Time date format (mmddyy hh:mm:ss)
Set date-time
G. Device status
H. Detailed setup
1. Output condition…
2. Device information…
I. Review
1. Manufacturer (Honeywell)
2. Model (XNX)
3. Sensor type (e.g., Optima)
4. PV (%LEL)
5. Info min range (e.g., 100.00% LEL)
6. Info max range (e.g., 100.00% LEL)
7. PV % range (e.g., 0.00%)
8. PV Xfer fnctn (e.g., linear)
9. PV (e.g., 4.000 mA)
PV alrm typ (e.g., none)
Tag (e.g., S. tower)
Long tag
Descriptor (e.g., South tower)
Message (e.g., Cracking tower)
Final asmbly num (e.g., 0)
Dev id (e.g., 1081234)
Universal rev (e.g., 6)
Fld dev rev (e.g., 1)
Software rev (e.g., 38)
Poll addr (e.g., 0)
Loop curnt mode (e.g., Enabled)
Cfg chng count (e.g., 6)
Num req preams (e.g., 9)
Num resp preams (e.g., 7)
II. Concentration
III. PV Alrm Typ
IV. Monitoring State
V. Reset Alarm Fault(s)
VI. Gas Name
VII.Sensor Type
