Hootoo HT-TM05 TripMate User Manual

131
USB host interface
In power on mode , it
can connect USB
storage for WiFi
accessing. In power
on &off mode, It can
charge your mobile
device(iPhone/iPAD/i
PAD mini, other
smart phone/PAD) ,
up to 2.1A current.
WAN port
RJ45 100Mbit/s
Battery
Capacity
10400mAh 4
x18650 battery
Charging current
1.6A
Discharge Current
Max 2.1A
Over current protection
Up to 2.1A by CMOS
PWM
Environmental
requirements
 Operating Temperature: 5°C to 35°C
 Non-Operating Temperature: 0°C to 60°C
 Operating Humidity: 5% to 90% (Non-condensing)
 Non-operating Humidity: 5% ~ 90 %
(Non-condensing)
Product
dimension
96mm L x44mm W x 44mm H
Emission (EMI),
Safety & Other
Certifications
 FCC Class B
 CE
