How to assemble hose
and converter
By using this converter attach-
ment, suction is channeled from
the cleaner to the hose and clean-
ing tools.
The converter must first be as-
sembled to the hose by inserting
the converter into the hose con-
nector.
Push connector and converter to-
gether and twist until the projec-
tions on the converter fit into the
holes on the hose connector. This
unit should remain assembled for
all future tool use.
Using cleaning tools
A. Attach converter
Disconnect cleaner from elec-
trical outlet. Cleaner must not be
plugged in when positioning or
removing converter.
With cleaner in upright position,
grasp handle and lean cleaner
backwards until bag is flat on the
floor and underside is accessible.
I
CONNECTOR CONVERTER
Turn lock on converter so that the
serrated portion is in line with the
hose.
Place projections on converter
onto rim on bottom plate of
cleaner. Pivot converter until it
covers the opening.
9
