3E-flite DHC-2 Beaver ARF Assembly Manual
Using the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed next
to each step to keep track of each step completed. Steps with
a single circle () are performed once, while steps with two
circles ( ) indicate that the step will require repeating, such
as for a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Contents of Kit/Parts Layout
Large Parts:
EFL4526 Wing Set
EFL4527 Fuselage
EFL4528 Tail Set
Small parts:
EFL4529 Cowling
EFL4530 Window Set
EFL4531 Landing Gear
EFL4532 Battery Hatch
EFL4533 Pushrod Set
EFL4534 Tailwheel Set
EFL4535 Wing Struts
EFL4536 Float Mount
EFL4538 Tailcone
EFL4539 Dummy Motor
