TR10A108-B RE / 02.2013
37
If the position of the operator is known, it is automatically 4.
transmitted back.
Hand transmitter reset8.6
Each hand transmitter button is assigned to a new radio code
by means of the following steps.
Open the battery lid and remove the battery for 1.
10 seconds.
Press a hand transmitter button and keep it pressed.2.
Insert the battery and close the battery lid.3.
The LED slowly flashes in blue for 4 seconds.–
The LED flashes rapidly in blue for 2 seconds.–
The LED is illuminated blue for a long time.–
Release the hand transmitter button.4.
All radio codes are newly assigned.
NOTE:
If the hand transmitter button is released prematurely, no new
radio codes are assigned.
LED display8.7
Blue (BU)
Condition Function
Illuminated for
2 seconds
A radio code is being transmitted
Flashes slowly Hand transmitter is in the learn mode
Flashes quickly after
slow flashing
A valid radio code was detected
during the learning run
Flashes slowly
for 4 seconds
Flashes quickly
for 2 seconds
Illuminated long
Device reset is being performed
or completed
Red (RD)
Condition Function
Flashes 2 × The battery is almost empty
Flashes slowly 3 × Position: door is not closed
Blue (BU) and Red (RD)
Condition Function
Flashing alternately Hand transmitter is in inherit / transmit
mode
Orange (OG)
Condition Function
Is illuminated
for 5 seconds
The door position query has been
activated
Flashes slowly
for 5 seconds
The position is queried
Flashes quickly 4 × The operator is out of reach
Illuminated briefly The position is queried every 5 s
Green (GN)
Condition Function
Flashes quickly
for 3 seconds
Position: door is closed
Cleaning the hand transmitter8.8
ATTENTION
Damaging the hand transmitter by faulty cleaning
Cleaning the hand transmitter with unsuitable cleaning
agents can damage the hand transmitter housing as well
as the hand transmitter buttons.
Clean the hand transmitter with a clean, soft, damp cloth.
▶
NOTE:
White hand transmitter buttons can change their colour when
used regularly over an extended period of time, if they come in
contact with cosmetic products (e.g. hand cream).
Disposal8.9
Electrical and electronic devices as well as batteries
may not be disposed of in household rubbish, but
must be returned to the appropriate recycling
facilities.
Technical data8.10
Type Hand transmitter HS 5 BiSecur
Frequency 868 MHz
Power supply 1 × 1.5 V battery,
type: AAA (LR 03)
Perm. ambient temperature – 20 °C to + 60 °C
Protection category IP 20
Excerpt from the declaration of conformity for 8.11
the hand transmitter
Conformity of the abovementioned product with the
requirements of the directives according to article 3 of the
R & TTE directives 1999/5/EC was verified by compliance
with the following standards:
EN 60950:2000ō
EN 300 220-1ō
EN 300 220-3ō
EN 301 489-1ō
EN 300 489-3ō
The original declaration of conformity can be requested from
the manufacturer.
External radio receiver*9
If there is a limited range, the functions impulse, operator light
or partial opening can be controlled with an external radio
receiver.
If an external radio receiver is retrofitted, the data in the
integrated radio module must be deleted (see section 6.1.12).
NOTE:
The antenna wire of external receivers should not come into
contact with metal objects (nails, bracing, etc.). The best
alignment to achieve an optimum range must be established
by trial and error.
When used at the same time, GSM 900 mobile phones can
affect the range.
* Accessory, not included as standard equipment!
