II. General Information
A. Construction
1. Icemaker
Compressor
Rear
Float-Operated Water Valve
Air-Cooled Condenser and
Condenser Fan Motor
Front
Control Box
Water Reservoir
Evaporator Assembly
Gear Motor
Upper Rear Panel
Suction Temperature Safety
Drier
Bin Control Thermostat
Fig. 1
Front Panel
Louver
Top Panel
Power Switch
Gear Motor Protector (External Overload) Reset Switch
Ice Discharge Opening
Bin Control
Thermostat Bulb
Slope
C-100BAF-AD Shown
Lower Rear Panel
C-100BAF-AD Shown
