2. Ice Making Unit
Allen Head Cap Screw
Gear Motor
Spline Coupling
Housing and
Lower Bearing
O-Ring
Mechanical Seal
Cylinder
Auger
Extruding Head
and Upper
Bearing
Cutter (motionless)
Insulation
Allen Head
Cap Screw
with Washer
Hex Head
Bolt with
Washer
Fig. 2
Evaporator Flange
