Hotpoint FDW 70 - Description of the appliance; Overall view; Control panel; Display

7
EN
Overall view
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control panel
***
***Only in completely built-in models.
* Only available in selected models.
Control panel
Display
Description of the appliance
WASH CYCLE
SELECT button
START/RESET
button
DISPLAY
ON/OFF
STAND BY
Button
DELAY START
button*
4IN1 button*
HALF LOAD button*
PRE-WASH
WASH
DRYING
RINSE
4IN1 indicator light*
HALF LOAD indicator light*
DELAY START indicator light*
WASH CYCLE
indicator light
LOW SALT
indicator light*
LOW RINSE AID
indicator light*
WASH CYCLE PHASE
indicator lights
