ELECTRICAL
CONNECTION
2.5" (6.4 cm) Height
from ground)
JETSETTER LX & JETSETTER
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
(Front view)
(Bottom view)
DOOR SIDE
•
22 leveling points (place shims at illustrated locations ).
DOOR
MAIN DRAIN
SECONDARY DRAIN
UPSIDE DOWN VIEW OF SPA
ELECTRICAL
CONNECTION
2.5" (6.4 cm)
Height from
ground)
Electrical Connection
(Both sides)
Page 11 Pre-Delivery Instructions
