HotSpring HIGHLIFE Series - Page 10

x Page x x
Pre-Delivery Instructions Page 10
PRODIGY
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
•
29 leveling points (place shims at illustrated locations).
66" (168 cm)
43" (109 cm)
7 " (17.8 cm)
29 " (74 cm)
33" (84 cm)
84" (213 cm)
19" (48 cm)22 " (56 cm)
19.5" (49.5 cm)
Prodigy
33" (84 cm)
6" (15.2 cm)
40" (101.5 cm)
55" (140 cm)
21" (53 cm)
78" (198 cm)
15"
(38 cm)
DOOR SIDE
UPSIDE DOWN VIEW OF SPA
DOOR
ELECTRICAL CONNECTION
2.5" (6.4 cm) Height
from ground)
MAIN DRAIN
SECONDARY DRAIN
ELECTRICAL
CONNECTION
2.5" (6.4 cm)
Height from
ground)
(Front view)
(Bottom view)
Electrical Connection
(Both sides)
