HotSpring HIGHLIFE Series Pre-Delivery Instructions

x Page x xx Page x x
L1 #10 AWG BLUE
54321
L2 #10 AWG RED
N #12 AWG WHITE
L2 #12 AWG RED
L2
L1
L1 #12 AWG BLUE
GRD
GROUND #10 AWG GREEN
GRD
#8 AWG WHITE, NEUTRAL
#10 AWG GREEN, GROUND
#8 AWG BLUE, L1
#8 AWG RED, L2
N
20A
50A
230V, 50 Amp,
2–POLE,
CIRCUIT BREAKER
(NON GFCI)
30A
LESS THAN 100 FT.
MAIN SERVICE
ELECTRICAL
PANEL
CONTROL BOX
TB1
HEATER
GROUND
SOVEREIGN (IIN), TRIUMPH (TRHN) & JETSETTER LX (JTN)
230 volt permanently connected models
*PROVIDED WITH SPA. NOTE: ALL WIRING SHOULD BE COPPER.
NOTE: The wire connections to GFCI breakers are for reference only. Always ensure the white neutral wire is
connected to the load neutral of the 20 amp breaker.
WARNING! The exact physical location of the terminals on the GFCI
breaker will vary between manufacturers. Connecting the hot wire
to the neutral terminal will cause irreversible damage to the control
box.
See owner’s
manual or
control box
schematic
for electrical
connection
details.
Pre-Delivery Instructions Page 14
PRODIGY (Model HN) & JETSETTER (Model JJN)
230 volt converted model
NOTE: The wire connections to GFCI breakers are for reference only. Always ensure the white neutral wire is connected to the
load neutral of the 20 amp breaker.
* Refer to NEC 250-122 (table)
AVAILABLE FROM DEALER. NOTE: ALL WIRING SHOULD BE COPPER.
WARNING! The exact physical location of the terminals on the
GFCI breaker will vary between manufacturers. Connecting the
hot wire to the neutral terminal will cause irreversible damage to
the control box.
See owner’s
manual or control
box schematic
for electrical
connection
details.
(1.5 m).
(15 m).
(30 m)
(1.5 m).
(15 m).
(30 m)

HotSpring HIGHLIFE Series Specifications

General

Water Care System	FreshWater Salt System
Lighting	LED lighting
Pump	Varies by model
Filtration System	Tri-X filter
Warranty	Varies by model (5-7 years)
Jet Count	Varies by model (approx. 35-50 jets)
