Page 13
SX (MODEL SX)
HORIZONTAL DIMENSIONS: ............. 72” (183cm.) square
HEIGHT (without cover): .................. 33” (83.8 cm.)
EFFECTIVE FILTER AREA: ................30 sq. ft. (2.79 m²)
HEATER: .............................. 1000 watts (1.0 kW), 4000 watts (4.0 kW) @ 230 volts
WATER (capacity): ...................... 285 gallons (1078 liters)
WEIGHT: .............................. 718 lbs. dry (326 kg.), 3620 lbs. filled (1642 kg.)
(Includes weight of water and 3 adults @ 175/lbs/79kg. each)
DEAD WEIGHT (filled): ...................130 lbs. per sq. ft., 635 kg. per m²
ELECTRICAL REQUIREMENTS: .......... 115 volt 20 amp grounded circuit
115 volt 30 amp grounded circuit (optional) - requires 30 amp subpanel
230 volt 50 amp single phase G.F.C.I. circuit (optional) - requires 50 amp subpanel
NOTE: ................................ 30/50 amp wiring must be performed by a licensed electrician.
CERTIFICATIONS: ...................... ETL Listed
OVERHEAD VIEW
A. Control Panel
B. Spa Light
C. Filter Lid
D. Pillow
E. Directional PRECISION
Jet
F. Moto-Massage
®
Jet
G. Air Control
lever
H. Suction
I. Floor Drain
A
B
C
D
E
F
H
G
I
D
F
E
Spa Specifications & Illustration Page 13
