Page 14
TX (MODEL TX)
HORIZONTAL DIMENSIONS: ............. 68.5" x 68.5" (174 cm x 174 cm)
HEIGHT (without cover): .................. 29” (74 cm.)
EFFECTIVE FILTER AREA: ................30 sq. ft. (2.7 m²)
HEATER: .............................. 1000 watts (1.0 kW) @ 115V 15 amp, 4000 watts (4.0 kW) @ 230 volts
WATER (capacity): ...................... 140 gallons (530 liters)
WEIGHT: .............................. 526 lbs. dry (239 kg.), 2044 lbs. filled (927 kg.)
(Includes weight of water and 2 adults @ 175lbs./79kg. each)
DEAD WEIGHT (filled): ...................100 lbs. per sq. ft., 488 kg. per m²
ELECTRICAL REQUIREMENTS: .......... 115 volt 15 amp grounded circuit
115 volt 30 amp grounded circuit (optional) - requires 30 amp subpanel
230 volt 50 amp single phase G.F.C.I. circuit (optional) - requires 50 amp subpanel
NOTE: ................................ 30/50 amp wiring must be performed by a licensed electrician.
CERTIFICATIONS: ...................... ETL Listed
OVERHEAD VIEW
A. Control Panel
B. Spa Light
C. Filter Lid
D. Pillow
E. Directional PRECISION
Jet
F. Rotary Hydromassage Jet
G. MOTO-MASSAGE Jet
H. Air Control
Lever
I. Floor Drain
J Suction
A
B
C
D
E
F
G
H
J
I
Page 14 Spa Specifications & Illustration
