JET MENUS
PRISM (MODEL PSM)
Jet Pump 3 - Jet System 1
Diverter lever in the position
Jet Pump 3 - Jet System 2
Diverter lever in the position
A
E
C
B
D
A
C
B
D
A
E
C
B
D
Jet Pump 1 - Jet System 2
Diverter lever in the position
A
E
C
BD
Jet Pump 1 - Jet System 1
Diverter lever in the position
A
E C
B
D
a. 1 Waterfall (lever must be in ON position
b. 2 Standard Single Rotary jets
c. 4 Directional PRECISION jets
d. 6 Directional PRECISION jets
e. 4 Rotary PRECISION jets
f. 4 Rotary PRECISION jets
g. 1 XL Dual Rotary jet
F G
a. 1 Waterfall (lever must be in ON position
b. 1 XL Directional jets
c. 4 Standard Dual Rotary jets
d. 1 Standard Dual Rotary jets
e. 6 Directional PRECISION jets
f. 5 Directional PRECISION jets
Jet Pump 2
a. 4 Directional PRECISION jets
b. 2 Standard Single Rotary jets
c. 2 XL Directional jets
d. 2 Directional PRECISION jets
e. 2 Rotary PRECISION jets
f. 4 Directional PRECISION jets
g. 2 Standard Directional jets
D
E
F
G
a. 6 Directional PRECISION jets
b. 2 Standard Dual Rotary jets
c. 2 XL Single Rotary jets
d. 4 Directional PRECISION jets
e. 2 Standard Directional jets
a. 6 Directional PRECISION jets
b. 2 Standard Dual Rotary jets
c. 2 XL Single Rotary jets
d. 1 XXL Jet
F
