HotSpring Vanguard User Manual

Page 7
Installation Instructions
ENVOY
™
(MODEL KK)
Leveling Points
NOTE: All dimensions are approximate; measure your spa before
making critical design or pathway decisions.
• 15 leveling points (place shims approx. 18” in from edge, then center middle shims).
21 1/4" (54 cm)
20 " (50.8 cm)
20 " (50.8 cm) 20 1/4 " (56.5 cm)
89 " (226 cm)
93" (236.2 cm)
18" (45.7cm)
18" (45.7cm)
44 1/2" (113.0cm)
44 1/2" (113.0cm)
UPSIDE DOWN VIEW OF SPA
