HM.3 Series Pump Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
24 8.717-210.0 1 CLOSED BEARING HOUSING
25 9.803-192.0 2 O-RING Ø1.78 X 60.05
26 8.933-011.0 2 TAPERED ROLLER BEARING
27 8.751-222.0 1 CRANKSHAFT (3540)
- 8.751-223.0 1 CRANKSHAFT
( 4030, 4035)
- 8.717-063.0 1 CRANKSHAFT (4031)
28 9.803-167.0 1 CRANKSHAFT KEY
29 9.802-921.0 1 OIL DIP STICK
30 9.803-140.0 1 CRANKSHAFT SEAL
31 9.803-178.0 2 SHIM
32 8.717-209.0 1 BEARING HOUSING
33 - 3 PLUNGER NUT, M8 SEE KITS BELOW
34 - 3 COPPER SPACER
SEE KITS BELOW
35 - 3 PLUNGER SEE KITS BELOW
36 - 3 COPPER SPACER
SEE KITS BELOW
37 - 3 O-RING SEE KITS BELOW
38 - 3 TEFLON RING SEE KITS BELOW
39 8.751-224.0 3 PLUNGER ROD (4030, 4031, 4035)
- 8.751-225.0 3 PLUNGER ROD (3540)
40 9.803-158.0 3 CONNECTING ROD
41 8.751-228.0 3 CONNECTING ROD PIN
42 9.803-218.0 6 SPRING WASHER
43 9.803-238.0 6 CONNECTING ROD SCREW
44 70-060009 1 O-RING, Ø2.62 X 126.67
REPAIR KIT # 8.725-360.0 8.725-362.0 8.725-358.0 8.725-361.0 8.725-363.0 8.725-359.0
DESCRIPTION
PLUNGER SEAL
4035
18MM
PLUNGER SEAL
4030, 4031
20MM
PLUNGER SEAL
3540
15MM
COMPLETE
SEAL PACKING
4035
18MM
COMPLETE
SEAL PACKING
4030, 4031
20MM
COMPLETE
SEAL PACKING
3540
15MM
ITEMS
INCLUDED IN
KIT
3,5,7 3,5,7 3,5,7 3,4,5,6,7 3,4,5,6,7 3,4,5,6,7
# OF CYLIN-
DERS KIT WILL
SERVICE
333111
REPAIR KIT # 8.751-237.0 8.751-238.0 8.933-023.0 9.802-603.0 9.802-609.0
DESCRIPTION
PLUNGER
4035
18MM
PLUNGER
4030, 4031
20MM
PLUNGER
3540
15MM
COMPLETE
VALVE
PLUNGER OIL
SEALS
ITEMS
INCLUDED IN
KIT
33,34,35,
36,37,38
33,34,35,
36,37,38
33,34,35,
36,37,38
11,12,13 2
# OF CYLIN-
DERS KIT WILL
SERVICE
11163
