Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
1 - - UNLOADER, SEE SPECIFICATIONS PAGES
2 - - PUMP, SEE SPECIFICATIONS PAGES
3 - - MOTOR, SEE SPECIFICATIONS PAGES
4 - - OVERLOAD, SEE SPECIFICATIONS PAGES
5 - - TRANSFORMER, SEE SPECIFICATIONS PAGES
6 - - FUSE, SEE SPECIFICATIONS PAGES
7 - - FUSE, SEE SPECIFICATIONS PAGES
8 - - CONTACTOR, SEE SPECIFICATIONS PAGES
9 9.802-259.0 18" HOSE, 1/2” PUSH ON
10 9.802-457.0 4” DIN RAIL, 35 MM
- - 6” DIN RAIL, 35 MM (TIME DELAY OPTION)
11 9.802-476.0 1
BOX, PLASTIC, 10" X 8" X 6" W/LID
(ALL MODELS EXCEPT 1710)
- 9.802-475.0 1 BOX, PLASTIC, 8" X 8" X 4" W/LID (ONLY 1710)
12 9.803-038.0 1 BRACKET, SUPPORT FOR ELEC BOX
13 9.802-518.0 1
STRAIN RELIEF, 3/4” LQ TITE (1710,1720, 1722, 1723, 1724,
1725, 1745, 1755)
- 9.802-526.0 1
LOCKNUT, 3/4” CONDUIT (1720,1722, 1723, 1724, 1725,
1745, 1753, 1755)
NOT SHOWN
- 9.802-521.0 1 STRAIN RELIEF, 3/4” (1743, 1744, 1753, 1754)
- 9.802-526.0 1 LOCKNUT, 3/4” (1743, 1744, 1753, 1754)
NOT SHOWN
14 9.802-515.0 1 STRAIN RELIEF, STRT, LQ TITE, MED
- 9.802-524.0 1 LOCKNUT, 1/2” CONDUIT
NOT SHOWN
15 8.918-424.0 - HOSE, 3/8” X 25", 2 WIRE PRESSURE LOOP
16 9.803-670.0 1 PUMP PROTECTOR, 1/2” PTP,190°
17 9.802-042.0 1 ELBOW, 1/2” JIC, 3/8” FEM, 90°
18 9.802-039.0 1 ELBOW, 1/2” JIC, 3/8”, 90°
19 9.802-779.0 4 NUT, 3/8”, ESNA
- 9.802-776.0 4 NUT, 5/16”, ESNA (ONLY 1710)
- 9.802-777.0 4 NUT, 5/16”, ESNA (FOR 1710 SS OPTION)
- 9.802-780.0 4 NUT, 3/8”, ESNA SS (SS OPTION)
20 9.802-807.0 8 WASHER, 3/8”, SAE, FLAT
- 9.802-808.0 8 WASHER, 3/8”, SAE FLAT (SS OPTION)
- 8.718-980.0 8 WASHER, 5/16” SAE FLAT (ONLY 1710)
- 9.802-805.0 8 WASHER, 5/16” SAE FLAT (SS OPTION FOR 1710)
21 8.706-881.0 1 NIPPLE, 3/4” PIPE X 1/2” PIPE BRASS (1753, 1754, 1755)
- 8.706-790.0 1
NIPPLE, 1/2” CLOSE (1710,1720, 1722, 1723, 1724,1725,
1743, 1744, 1745)
22 8.706-844.0 1 TEE, 1/2” FEMALE, PIPE
23 9.802-128.0 1 NIPPLE, 1/2” JIC X 1/2” MPT PIPE
Hotsy 1700 Operator’s Manual 8.914-380.0 - W
