33Hotsy 1700 Operator’s Manual 8.914-380.0 - W
HX.2 Pump Series Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
22 - 6 VALVE CAGE SEE KIT BELOW
23 8.752-830.0 8 HEX SCREW
24 9.802-884.0 8 WASHER
25 9.803-182.0 1 CLOSED BEARING HOUSING
26 9.803-186.0 2 O-RING Ø2.62 X 71.12
27 9.803-160.0 2 ROLLER BEARING
28 8.752-828.0 1 CRANKSHAFT Ø25 (5843)
- 8.752-829.0 CRANKSHAFT Ø25 (8043, 9536)
- 8.752-827.0 1 CRANKSHAFT Ø25 (1036)
29 9.803-293.0 1 CRANKSHAFT KEY
30 8.752-834.0 1 OIL DIP STICK
31 9.803-139.0 1 CRANKSHAFT SEAL
32 9.803-177.0 2 SHIM
33 9.803-181.0 1 BEARING HOUSING
34 8.752-841.0 3 PLUNGER BOLT
35 8.752-820.0 3 BONDED SEAL
36 8.752-846.0 3 PLUNGER, 20MM (5843,8043)
- 8.752-847.0 3 PLUNGER, 22MM (9536,1036)
37 8.752-823.0 3 COPPER SPACER
38 8.752-842.0 3 PLUNGER ROD
39 8.752-822.0 3 CONNECTING ROD PIN
40 8.752-821.0 3 CONNECTING ROD
41 9.802-889.0 6 SPRING WASHER
42 9.802-937.0 6 CONNECTING ROD SCREW
43 9.803-194.0 1 O-RING Ø2.62 X 152.07
44 8.752-826.0 1 CRANKCASE COVER
45 9.803-906.0 1 O-RING Ø1.78 X 14.00
46 8.707-262.0 1 BRASS PLUG G3/8
47 9.803-202.0 1 SIGHT GLASS G3/4
48 8.752-824.0 5 COVER SCREW
REPAIR KIT # 8.752843.0 8.752-844.0 8.752-849.0 8.752-850.0 8.752-838.0 8.752.839.0 8.753-349.0 8.752-835.0
DESCRIPTION
PLUNGER
SEAL 20MM
(5843,8043)
PLUNGER
SEAL 20MM
(9536,1036)
SEAL
PACKING
20MM
(5843,8043)
SEAL
PACKING
22MM
(9536,1036)
PLUNGER
20MM,
(5843,8043)
PLUNGER
22MM
(9536,1036)
COMPLETE
VALVE
PLUNGER
OIL SEAL
ITEMS
INCLUDED IN
KIT
3,5,7 3,5,7 3,4,5,6,7 3,4,5,6,7 34,35,36,37 34,35,36,37 11,12,13 2
# OF
CYLINDERS KIT
WILL SERVICE
33111163
