6 Technical data
6.1 Application limits
Extract air temperature max. °C 50
Supply air temperature max. °C 60
Temperature of the heating medium
1)
max. °C 90
Pressure of the heating medium max. kPa 800
Air flow rate Size 6:
Size 9:
min.
min.
m³/h
m³/h
3100
5000
Condensate quantity Size 6:
Size 9:
max.
max.
kg/h
kg/h
90
150
The units cannot be used in:
■ Damp locations
■ Places with a corrosive or aggressive environment
■ Spaces with a large amount of dust
■ Areas where there is danger of explosion
1)
Design for higher temperatures on request
Table 4: Application limits
6.2 Electrical connection
Unit type TH-6
MH-6
TH-9
MH-9
TC, THC,
MC, MHC
Supply voltage V AC 3 × 400 3 × 400 3 × 400
Permitted voltage tolerance % ± 5 ± 5 ± 5
Frequency Hz 50 50 50
Connected load kW 1.5 2.1 3.6
Current consumption max. A 2.9 4.0 5.9
Series fuse A 13 13 13
Protection rating - IP 54 IP 54 IP 54
Table 5: Electrical connection
6.3 Air flow rate
Unit size 6 9
Nominal air flow rate m³/h 6000 9000
Floor area covered m² 537 946
Table 6: Air ow rate
12
TopVent
®
TH
|
TC
|
THC
|
MH
|
MC
|
MHC
Operating instructions
Technical data
4 218 828-en-01 4 218 828-en-01
