6.4 Heat output
TopVent
®
TH, TC, THC recirculation units
Unit size Coil type
Heat performance
P
rated,h
(in kW)
6
A 13.2
B 18.9
C 29.8
9
A 22.6
B 28.5
C 46.2
D 54.2
Reference: Standard rating conditions for fan coil units
according to Commission Regulation (EU)
2016/2281
■ Room air temperature ..................20 °C
■ Extract air temperature ................22 °C
■ Fan ..............................................speed 2
■ Heating medium temperature.......45/40 °C
Table 7: TopVent
®
TH, TC, THC heat output
TopVent
®
MH, MC, MHC supply air units
Unit size Coil type
Heat performance
P
rated,h
(in kW)
6
A 13.2
B 18.9
C 29.8
9
A 22.6
B 28.5
C 46.2
D 54.2
Reference: Standard rating conditions for fan coil units
according to Commission Regulation (EU)
2016/2281
■ Room air temperature ..................20 °C
■ Extract air temperature ................22 °C
■ Fresh air temperature ..................12 °C
■ Fresh air ratio ..............................10%
■ Fan ..............................................speed 2
■ Heating medium temperature.......45/40 °C
Table 8: TopVent
®
MH, MC, MHC heat output
6.5 Cooling capacity
TopVent
®
TC, THC recirculation units
Unit size
Coil
type
Cooling capacity
(sensible)
(P
rated,c
) (in kW)
Cooling capacity
(latent)
(P
rated,c
) (in kW)
6 C 26.5 5.6
9
C 41.0 7.3
D 48.6 15.2
Reference: Standard rating conditions for fan coil units according to
Commission Regulation (EU) 2016/2281
■ Room air temperature .................. 27 °C (dry bulb)
19 °C (wet bulb)
■ Room air humidity ........................ 46.26 % rH
■ Extract air temperature ................29 °C
■ Fan ..............................................speed 2
■ Cooling medium temperature ....... 7/12 °C
Table 9: TopVent
®
TC, THC cooling capacity
TopVent
®
MC, MHC supply air units
Unit size
Coil
type
Cooling capacity
(sensible)
(P
rated,c
) (in kW)
Cooling capacity
(latent)
(P
rated,c
) (in kW)
6 C 26.5 5.6
9
C 41.0 7.3
D 48.6 15.2
Reference: Standard rating conditions for fan coil units according to
Commission Regulation (EU) 2016/2281
■ Room air temperature .................. 27 °C (dry bulb)
19 °C (wet bulb)
■ Room air humidity ........................ 46.26 % rH
■ Extract air temperature ................29 °C
■ Fresh air temperature ..................32 °C
■ Fan ..............................................speed 2
■ Cooling medium temperature ....... 7/12 °C
Table 10: TopVent
®
MC, MHC cooling capacity
