Hover-1 H1 - Introduction

OPERATING PRINCIPALS
The device uses digital electronic gyroscopes and acceleration
sensors to control balance and motion, depending on the user's
center of gravity. The device also uses a control system to drive the
motors that are located within the wheels. The device has a built-in
inertia dynamic stabilization system that can help assist with balance
when moving forward and backwards, but not while turning.
TIP – To increase your stability, you must shift your weight in order to
overcome the centrifugal force during turns, especially when
entering a turn at higher speeds.
Model: HY-H1
Net Weight: 22.04 lbs (10 kg)
Load: 44-265 lbs (20-120 kg)
Max Speed: Up to 9 mph (14.4 km/h)
Max Distance Range: Up to 9 miles (14.4 km)
Max Incline Angle: 15°
Minimum Turning Radius: 0°
Battery Type: Lithium-ion
Battery Voltage: 36 V
Battery Capacity: 4.0 Ah
Power Requirement: AC 100-240V, 50-60 Hz
Wheel Size: 6.5 Inches (16.51 cm)
Tire Type: Non-Pneumatic Solid Tires
IP Rating: IPX4
Bluetooth Range: Up to 33ft
Bluetooth Speaker: V2.0 with stereo sound quality
UL Certification: UL 2272 approved
FCC ID: 2AANZH1
BT ID: D037690
The Hover-1 H1 is a personal transporter. Our technology and
production processes are developed with strict testing for each H1
scooter. Operating the H1 without following the contents of this
manual may lead to damage to your H1, or bodily injury.
This manual is designed to give you the information you need for the
safe operation and maintenance of your H1. Please read it
thoroughly before riding your H1.
PACKAGE CONTENTS
• Hover-1 H1 Electric Scooter
• 3-pin Charge Cable
• Operation Manual
FEATURES/PARTS
1. Fender 6. Tire
2. Left Foot Mat 7. LED Light
3. Running Indicator 8. Charge Port (located in rear)
4. Battery Indicator 9. Power Button (located in rear)
5. Right Foot Mat 10. Wireless Speaker
INTRODUCTION
10
1 1
7
6
6
7
7 7
2
3
4
5
8 9
4
