Planning dimensions - Profile kitchens Planning dimensions - Larder
Kitchen installation manual
End and mid larder profiles
Important fitting information
Ensure cabinets are perfectly aligned and level before fitting profiles.
Profiles must be fitted flush with the top edge of the cabinet end panels.
Fit the top door first so it is flush with the top edge of the profile.
NOTE: If you have a low ceiling height which is touching the top of the profile,
adjust the door down 2mm to give clearance.
Profile
Door DoorProfile
Door
Low Ceiling
Door
2mm
Profile
