Howdens 931 - Planning Dimensions - Deep Wall Cabinets

9www.howdens.com
Planning dimensions - Standard cabinets
Planning dimensions - Deep wall cabinets
Kitchen installation manual
170mm
720mm
A
A
C
C
B
B
28/38/
40mm
390mm
Concealed wall
hanging brackets
Wall fixing
back rail
Base cabinet
fixing bracket
575mm
616mm
890mm
1942mm
2122mm
720mm (full height)
557mm (standard)
900mm (extra tall)
502mm
464mm
(based on 38mm worktop)
2112mm (standard)
2292mm (extra tall)
CONSIDERATIONS
• Use 25mm screws for 12mm decor ends.
