HP Enterprise HPE 5820 Switch Series User Manual

12
The SFP+ modules and SFP+ cables available for the switch are subject to change over time. For
the most up-to-date list of SFP+ modules and cables, contact Hewlett Packard Enterprise technical
support or marketing staff.
IRF port binding restrictions
Chassis
Candidate physical IRF
ports
Requirements
• 5800-48G-PoE+ Switch
with 2 Interface Slots
(JC101A/JC101B)
• 5800-48G-PoE+ TAA
Switch with 2 Interface
Slots
(JG242A/JG242B)
Ports on the expansion interface
cards on the front panel
All physical ports of an IRF port must
be located on the same interface card.
5800AF-48G Switch
(JG225A/JG225B)
The six fixed SFP+ ports (in two
groups) on the front panel:
• SFP+ ports 49, 50, and 52 in
one group
• SFP+ ports 51, 53, and 54 in
the other group
All physical ports of an IRF port must
be in the same group.
• 5800-48G Switch with 1
Interface Slot
(JC105A/JC105B)
• 5800-48G TAA Switch
with 1 Interface Slot
(JG258A/JG258B)
• 5800-48G-PoE+ Switch
with 1 Interface Slot
(JC104A/JC104B)
• 5800-48G-PoE+ TAA
Switch with 1 Interface
Slot (JG257A/JC257B)
• The four fixed SFP+ ports on
the front panel
• Ports on the expansion
interface card on the rear
panel
All physical ports of an IRF port must
be located on the front panel or the
interface card on the rear panel.
• 5800-24G Switch
(JC100A/JC100B)
• 5800-24G TAA Switch
(JG255A/JG255B)
• 5800-24G-PoE+ Switch
(JC099A/JC099B)
• 5800-24G-PoE+TAA
Switch
(JG254A/JG254B)
• The four fixed SFP+ ports on
the front panel
• Ports on the expansion
interface card on the rear
panel
No location restriction for the physical
ports of an IRF port.
• 5800-24G-SFP Switch
with 1 Interface Slot
(JC103A/JC103B)
• 5800-24G-SFP TAA
Switch with 1 Interface
Slot (JG256A/JG256B)
• The four fixed SFP+ ports on
the front panel
• Ports on the expansion
interface card on the front
panel
No location restriction for the physical
ports of an IRF port.
• 5820X-14XG-SFP+
Switch with 2 Interface
Slots (JC106A/JC106B)
• 5820X-14XG-SFP+
TAA Switch with 2
Interface Slots
(JG259A/JG259B)
• The 14 fixed SFP+ ports on
the front panel
• Ports on the expansion
interface card on the front
panel
No location restriction for the physical
ports of an IRF port.
