HP 10400A OPERATING NOTE
NOTE
Six to eight pounds of force is required
to disconnect and connect the probe tip
and probe cable. To increase grip on
probe tip barrel, wind a rubber band
around the barrel several times to
provide a non-slip grip.
CAUTION
Do not use tools (pliers, etc.) to install
probe tip. Tools may damage circuitry
located in the probe tip. Use rubber
band as indicated in previous note.
3. Connect probe tip assembly to cable
assembly by grasping probe cable tightly
and push tip onto cable end until a positive
click is heard and tip barrel is bottomed
out against shoulder on cable
interconnect.
