HP 15z-cw100 User Manual

3. Remove the battery (see Battery on page 29).
4. Remove the right speaker (see Speakers on page 35).
Remove the ngerprint reader:
1. Disconnect the cable from the ZIF connector on the ngerprint reader board (1).
2. Remove the Phillips M2.0 × 3.0 screw (2) that secures the ngerprint reader bracket to the computer.
3. Remove the bracket from on top of the ngerprint reader (3).
4. Remove the ngerprint reader from the computer (4).
Reverse this procedure to install the ngerprint reader.
Fan
To remove the fan, use this procedure and illustration.
Table
5-9 Fan description and part number
Description Spare part number
Fan M08945-001
Before removing the fan, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the bottom cover (Bottom cover on page 27).
3. Remove the battery (see Battery on page 29).
Remove the fan:
Component replacement procedures 37

HP 15z-cw100 Specifications

General

Storage	256GB PCIe NVMe M.2 SSD
Operating System	Windows 10 Home
Battery	3-cell, 41 Wh Li-ion
Audio	Dual speakers
Color	Natural Silver
RAM	8GB DDR4-2400 SDRAM
Weight	4.08 lb
Wireless	Realtek RTL8821CE 802.11b/g/n/ac (1x1) and Bluetooth 4.2
Ports	1 HDMI 1.4b; 1 RJ-45; 1 headphone/microphone combo
Dimensions	14.11 x 9.53 x 0. in
Graphics	AMD Radeon Vega 8 Graphics
