Note Number HP Part Number Title Description
Application Note 1225-3 5091-5447E
Digital Video Testing with the
HP 16542A
Uses the deep memory of the
HP 16542A with the complex
triggering capabilities of that
module and of the 16550A
state/timing analyzer to capture
and analyze data from a digital
video stream.
Application Note 1244-1 5962-8620E
Minimizing Intrusion Effects
When Probing with a Logic
Analyzer
Discusses physical and
electrical considerations for
probing circuits with an analyzer.
Application Note 1244-2 5091-8839E
Designing a Custom Interface
for a Logic Analyzer Using HP
User-Definable Design Tools
Describes various HP tools for
designing custom hardware and
software interfaces to newer or
less common chips and buses.
Application Note 1261 5091-8798E
Timing Charaterization Using the
HP 16517/18A with Intel
PentiumProcessor
Measurement Examples
Discusses how the timing
characterization of a digital
system can be performed more
efficiently with a high speed
logic analyzer.
Application Note 1266-1 5963-3544E
Intel 80960CA Software Debug
Using a Logic Analyzer and an
In-Circuit Debugger
Explains how to integrate a logic
analyzer with the MRI Debugger
Monitor for the Intel 80960 CA
processor.
Product Note 16522-1 5964-6347E
Digital Verification with the
HP 16522 Pattern Generator
Shows how to use the pattern
generator with the timing
analyzer to do board verification.
Product Note 54720A-3 5091-3758E
Selecting Oscilloscope Probes
for High-Speed Digital Circuit
Measurements
Discusses loading effects of
probes on digital circuitry. Very
relevant to probing for logic
state and timing analysis as well.
Application Notes
6–3
