To load a measurement configuration
You can quickly load a previously saved measurement configuration, saving
the trouble of manually setting up the measurement parameters for each
module.
1
Select System from the module field.
2 Select Hard Disk or Flexible Disk from the Menu field.
Your choice here depends on where you saved the configuration.
3 Select Load from the disk operations field.
4 Select the module for which you want to load a configuration from
the module list.
You can load configurations for individual modules. The choice “System”
loads only the mainframe configuration. The choice “All” loads the mainframe
configuration and that of all measurement modules.
However, you can only load configurations that are defined in the
configuration file itself. Thus, if you select System, then select a file that
contains only an analyzer configuration, the configuration will fail.
If you save an analyzer configuration as “All,” then attempt to reload that
configuration into a particular measurement module, configuration will fail.
Also, configurations are slot dependent. If you save a configuration for a
particular module, rearrange the modules within the HP 16500C, then try to
reload the configuration, the configuration will not load.
5
Specify a file name from which to load the configuration using the
“from file” field.
6 Select Execute.
File Management
To load a measurement configuration
3–6
