HP 16500C

To save a measurement configuration
You can save measurement configurations on a 3.5-inch disk or on the
internal hard disk for later use. This is especially useful for automating
repetitive measurements for production testing.
1
Select System from the module field.
2 Select Hard Disk or Flexible Disk from the menu field.
3 Select Store from the disk operations field.
4 Select the module for which you want to save the configuration from
the module list.
You can save the configuration for individual modules. The choice “System”
saves only the mainframe configuration. The choice “All” saves the
mainframe configuration and that of all measurement modules.
5
Specify a file name into which to save the configuration using the “to
file” field.
6 Specify a descriptive comment for the file using the “file description”
field.
7 Select Execute.
File Management
To save a measurement configuration
3–4
