Transferring Files Using the Flexible Disk Drive

Because the flexible disk drive on the HP 16500C will read and write

double-sided, double density or high-density disks in MS-DOS format,

it is a useful tool for transferring images to and from IBM

PC-compatible computers as well as other systems that can read and

write MS-DOS format. You can save measurement configuration files,

measurement results, and even menu and measurement images from

the screen.

This section shows you how to use the flexible disk drive to:

• save a measurement configuration

• load a measurement configuration

• save a trace list in ASCII format

• save a screen image (such as an oscilloscope display or menu)

• load system software

If you need more information on the basic flexible disk drive

operations, see the HP 16500C/16501A Logic Analysis System

User’s Reference.
