If You Have a Problem

Occasionally, a measurement may not give the expected results. If you

encounter difficulties while making measurements, use this chapter to

guide you through some possible solutions. Each heading lists a

problem you may encounter, along with some possible solutions. Error

messages which may appear on the logic analyzer are listed below in

quotes “ ”. Symptoms are listed without quotes.

If you still have difficulty using the analyzer after trying the

suggestions in this chapter, please contact your local Hewlett-Packard

service center.

CAUTION

When you are working with the analyzer, be sure to power down both the

analyzer and the target system before disconnecting or connecting cables,

probes, and preprocessors. Otherwise, you may damage circuitry in the

analyzer, preprocessor, or target system.
