Table 9-3 Solid-state drive specications
256 GB* 512 GB* 1 TB*
Dimensions
Height 1.0 mm 1.0 mm 1.0 mm
Length 50.8 mm 50.8 mm 50.8 mm
Width 28.9 mm 28.9 mm 28.9 mm
Weight < 10 g < 10 g < 10 g
Interface type PCIe PCIe PCIe
Ready time, maximum (to not busy) 1.0 ms < 1.0 ms 1.0 ms
Access times, logical 0.1 ms 0.1 ms 0.1 ms
Transfer rate
Sequential read up to 2150 MBps up to 2150 MBps up to 2150 MBps
Random read Up to 300,000
IOPs
Up to 300,000
IOPs
Up to 300,000 IOPs
Sequential write up to 1550 MBps up to 1550 MBps up to 1550 MBps
Random write Up to 100,000
IOPs
Up to 100,000
IOPs
Up to 100,000 IOPs
Total logical sectors 468,883,296 1,000,215,216 1,500,336,388
Operating temperature 0°C to 70°C (32°F to 158°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible
capacity is less. Actual drive specications may dier slightly.
NOTE: Certain restrictions and exclusions apply. Contact support for details.
Solid-state drive specications 95
