HP 175X - JetDirect Print Server

Interpreting the configuration page
for HP Jetdirect 175x external print server/Internet connector for USB
and HP Jetdirect 310x external print server/Internet connector for USB
The configuration page (also called a self-test page or configuration plot) for a print server displays
messages, network statistics, and status for the print server. To print a configuration page, press the test
button on the print server. (For trouble, click here.)
An HP Jetdirect configuration page can also be viewed over the network from a management utility (such
as HP Web Jetadmin), or by accessing the embedded web server on the HP Jetdirect print server.
Below is a sample for the 310x print server. The page for the 175x is similar; a few sections do not apply.
● For a general description of a section, just click on any section of the configuration page below.
● For a specific description of each entry on your page, see the HP Jetdirect Administrator’s Guide.
Find the HP Jetdirect Configuration Page topic in its contents panel.
