Right side
Item Component Description
(1) Optical drive Reads and writes to an optical disc.
(2) Optical drive light
●
On: The optical drive is in use.
● Off: The optical drive is idle.
(3) USB ports (2) Connect optional USB devices.
(4) Power connector Connects an AC adapter.
(5) AC adapter light
●
White: The computer is connected to external
power and the battery is fully charged.
●
Amber: A battery is charging.
(6) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from
being mishandled or stolen.
Right side 13
