Display assembly subcomponents
Item Component Spare part number
(1) Display bezel:
For use with computer models equipped with a webcam and a microphone 646115-001
For use with computer models equipped only with a microphone 646116-001
(2) Display hinge covers (2) 646124-001
(3) 15.6-in, HD, LED, BrightView display panel 645096-001
(4) Webcam/microphone module 646138-001
Microphone module 645980-001
(5) Display Hinge Kit (includes left and right display hinges and brackets) 646123-001
(6) Display Cable Kit (includes display panel cable and webcam/microphone
module cable)
646120-001
(7) Antenna Kit (includes left and right wireless antenna cables and transceivers) 646111-001
(8) Display enclosure:
In black finish 664236-001
22 Chapter 3 Illustrated parts catalog
